16 of 28 PN: 11410-00698 Rev. B MT8220T TDS
Specifications BTS Master™ MT8220T
WiMAX Fixed/Mobile Measurements (Option 0885)
WiMAX Fixed Measurements
Setup Parameters
Bandwidth (MHz) 1.25, 1.50, 2.50, 3.50, 5.00, 5.50, 6.00, 7.00, 10.00
Cyclic Prefix Ratio (CP) 1/4, 1/8, 1/16, 1/32
Span (MHz) 5, 10, 15, 20
Frame Length (ms) 2.5, 5.0, 10.0
Frequency Center, Signal Standard, Channel #, Closest Channel, Decrement/Increment Channel
Amplitude Scale/Division, Power Offset, Auto Range, Adjust Range
Sweep Single/Continuous, Trigger Sweep
Save/Recall Setup, Measurement, Screen Shot (save only), to Internal/External Memory
Measurement Summary Screens Overall Measurements, RF Measurements, Modulation Measurements
WiMAX Fixed RF Measurements (temperature range 15 °C to 35 °C)
RF Channel Power Accuracy ± 1.5 dB; ± 1.0 dB typical, (RF input –50 dBm to +20 dBm)
WiMAX Fixed Demodulation Measurements (temperature range 15 °C to 35 °C)
Frequency Error 7 × 10 –8 + time base error 4 , 99 % confidence level
Residual EVM (rms) 3 % typical, 3.5 % maximum (RF Input –50 dBm to +20 dBm)
RF Demodulation Over-the-Air (OTA) Pass/Fail
Channel Spectrum
Channel Power
Occupied Bandwidth
Power vs. Time
Channel Power
Preamble Power
Data Burst Power
Crest Factor
ACPR
RF Summary
Constellation
RCE (RMS/Peak)
EVM (RMS/Peak)
Frequency Error
Carrier Frequency
Base Station ID
Spectral Flatness
Adjacent Subcarrier Flatness
EVM vs. Subcarrier/Symbol
RCE (RMS/Peak)
EVM (RMS/Peak)
Frequency Error
Carrier Frequency
Base Station ID
Sector ID (Mobile)
Modulation Summary
There are no additional OTA
Measurements
RF and Demodulation Measurements
can be made OTA
View Pass/Fail Limits
All, RF, Modulation
Available Measurements
Channel Power
Occupied Bandwidth
Burst Power
Preamble Power
Crest Factor
Frequency Error
Carrier Frequency
EVM
RCE
Base Station ID
