BTS Master™ MT8220T Software
MT8220T TDS PN: 11410-00698 Rev. B 19 of 28
Line Sweep Tools™
(for your PC)
Trace Capture
Browse to Instrument View and copy traces from the test equipment to your PC using Windows Explorer
Open Legacy Files Open DAT files captured with Handheld Software Tools v6.61
Open Current Files Open VNA or DAT files
Capture Plots To The Line Sweep Tools screen, DAT files, Database, or JPEG
Traces
Trace Types Return Loss, VSWR, DTF-RL, DTF-VSWR, Cable Loss, Smith Chart, and PIM
Trace Formats DAT, VNA, CSV, PNG, BMP, JPG, HTML, Data Base, and PDF
Report Generation
Report Generator Includes GPS location along with measurements
Report Format Create reports in HTML or PDF format
Report Setup Report Title, Company, Prepared for, Location, Date and Time, Filename, Company logo
Trace Setup 1 Trace Portrait Mode, 2 Trace Portrait Mode, 1 Trace Landscape Mode
Trace Validation
Presets 7 presets allow “one click” setting of up to 6 markers and one limit line
Marker Controls 6 regular Markers, Marker Peak, Marker Valley, Marker between, and frequency entry
Delta Markers 6 Delta markers
Limit Line Enable and drag or value entry. Also works with presets
Next Trace Button Next Trace and Previous Trace arrow keys allow quick switching between traces
Tools
Cable Editor Allows creation of custom cable parameters
Distance to Fault Converts a Return Loss trace to a Distance to Fault trace
Measurement Calculator Converts Real, Imaginary, Magnitude, Phase, RL, VSWR, Rho, and Transmit power
Signal Standard Editor Creates new band and channel tables
Renaming Grid 36 user definable phrases for creation of file names, trace titles, and trace subtitles
Connectivity Connections Ethernet, USB cable, and USB memory stick
Master Software Tools™
(for your PC)
Mapping (GPS Required)
Spectrum Analyzer Mode MapInfo, MapPoint
Mobile WiMAX OTA, LTE OTA Options Google Earth, Google Maps, MapInfo
Folder Spectrogram (Spectrum Monitoring for Interference Analysis and Spectrum Clearing)
Folder Spectrogram – 2D View Creates a composite file of multiple traces
Peak Power, Total Power, Peak Frequency, Histogram, Average Power (Max/Min)
File Filter (Violations over limit lines or deviations from averages)
Playback
Video Folder Spectrogram – 2D View Create AVI file to export for management review/reports
Folder Spectrogram – 3D View Views (Set Threshold, Markers)
- 3D (Rotate X, Y, Z Axis, Level Scale, Signal ID)
- 2D View (Frequency or Time Domain, Signal ID)
- Top Down
Playback (Frequency and/or Time Domain)
List/Parameter Editors
Traces Add, delete, and modify limit lines and markers
Product Updates Auto-checks Anritsu website for latest revision firmware
Pass/Fail Create, download, or edit Signal Analysis Pass/Fail Limits
Languages Add custom language or modify non-English language menus
Script Master™
Channel Scanner Mode Automate scan up to 1200 channels, repeat for sets of 20 channels, repeat all channels
GSM/GPRS/EDGE or W-CDMA/HSPA+
Mode Automate Signal Analysis testing requirements with annotated how-to pictures
Connectivity
Connections Connect to PC using USB or Ethernet
