6“ finishing palm sander – Astro Pneumatic 3025 6 Finishing Palm Sander - 3/32 Stroke Finish User Manual
Page 2
Page 2
3025
PART
NO.
QTY.
DESCRIPTION
3025-01
3025-02
3025-03
3025-04
3025-05
3025-06
3025-07
3025-08
3025-09
3025-10
3025-11
3025-12
3025-13
3025-14
3025-15
3025-16
3025-17
3025-18
3025-19
3025-20
3025-21
3025-22
1
1
1
2
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Housing
Housing Cover
Washer
O-Ring
Regulator
Regulator
Valve Stem
Pin
Muffler
Exhaust Deflector
Spacer
Controller
Spring
O-Ring
Air Inlet
Lever
Pin
Retaining Ring
Ball Bearing
Rear Plate
Pin
Rotor
PART
NO.
QTY.
DESCRIPTION
3025-23
3025-24
3025-25
3025-26
3025-27
3025-28
3025-29
3025-30
3025-31
3025-32
3025-33
3025-34
3025-34P
3025-35
3025-36
3025-37
3025-38
3025-39
3025-40
3025-41
3025-42
5
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Rotor Blade
Cylinder
O-Ring
Front Plate
Ball Bearing
O-Ring
Motor Cover
Balance
Set Screw
Rotor Shaft
Ball Bearing
Retaining Ring
Ball Bearing
Washer
Retaining Ring
Drive Spindle
Pad Cover
6” Pad
Wrench
Key
Set Screw
6“ Finishing Palm Sander
