2 typical electrical and mechanical specifications, Torque specification – Alpha Technologies AlphaCellTM SMU-C Series User Manual
Page 9
9
745-680-B11-001, Rev. A
Table 1-1, General Electrical and Mechanical Specifications by Model
(Specifications courtesy of manufacturer)
Type
Normal
Voltage
(V)
Rated
Capacity
C20 (Ah)
Rated Power
(15min, 1.75V, W)
Dimensions
L x W x H (in/mm)
WT
(lb/kg)
SMU-C 6-4.5
6
4.5
14.6
2.76 x 1.85 x 4.21 / 70 x 47 x 107
1.8 / .82
SMU-C 6-7
6
8.0
32.4
5.94 x 1.34 x 3.94 / 151 x 34 x 100
3.0 / 1.4
SMU-C 6-12
6
13.2
54.1
5.94 x 1.97 x 3.94 / 151 x 50 x 100
4.2 / 1.9
SMU-C 12-4.5
12
4.5
14.6
3.54 x 2.76 x 4.21 / 90 x 70 x 107
3.7 / 1.7
SMU-C 12-7
12
8.0
32.4
5.94 x 2.56 x 3.98 / 151 x 65 x 101
5.6 / 2.5
SMU-C 12-12
12
13.2
54.1
5.94 x 3.86 x 3.98 / 151 x 98 x 101
8.8 / 4.0
SMU-C 12-14
12
14.0
56.0
5.94 x 3.86 x 3.98 / 151 x 98 x 101
9.3 / 4.2
SMU-C 12-18
12
20
73.7
7.13 x 3.03 x 6.57 / 181 x 77 x 167
13.2 / 6.0
SMU-C 12-26
12
28
98.3
6.89 x 6.54 x 4.92 / 175 x 166 x 125
19.6 / 8.9
SMU-C 12-28
12
28
98.3
6.50 x 4.96 x 7.17 / 165 x 126 x 182
18.7 / 8.5
SMU-C 12-30
12
30
98.3
6.57 x 4.96 x 6.93 / 167 x 126 x 176
22.5 / 10.2
SMU-C 12-35
12
35
138
7.68 x 5.12 x 7.09 / 195 x 130 x 180
23.2 / 10.5
SMU-C 12-40
12
41
152
7.76 x 6.50 x 6.69 / 197 x 165 x 170
30.2 / 13.7
SMU-C 12-55
12
56
197
9.02 x 5.43 x 8.98 / 229 x 138 x 228
37.5 / 17.0
SMU-C 12-65
12
66
231
13.98 x 6.58 x 7.21 / 355 x 167 x 183
50.0 / 22.7
SMU-C 12-75
12
76
265
10.16 x 6.61 x 8.90 / 258 x 168 x 226
50.7 / 23.0
SMU-C 12-90
12
92
305
12.01 x 6.61 x 8.90 / 305 x 168 x 226
63.7 / 28.9
SMU-C 12-100
12
102
364
12.99 x 6.77 x 8.70 / 330 x 172 x 221
68.3 / 31.0
SMU-C 12-120
12
122
438
15.94 x 6.89 x 9.25 / 405 x 175 x 235
83.8 / 38.0
SMU-C 12-134
12
136
381
13.43 x 6.77 x 11.34 / 341 x 172 x 288
93.7 / 42.5
SMU-C 12-150
12
154
546
19.09 x 6.77 x 9.45 / 485 x 172 x 240
99.2 / 45.0
SMU-C 12-200
12
202
568
20.55 x 9.37 x 9.29 / 522 x 238 x 236
134.5 / 61.0
1.2 Typical Electrical and Mechanical Specifications
Torque Specification
Torque specifications are 8.0Nm (75lbf-in). Torque all terminal connections to the
specified value. Improper torquing can result in loose connections or damaged
terminals.
