27 745-680-B11-001, Rev. A
SMU-C 12-100
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 767 491 375 225 131 56.4 32.9 21.8 11.4
1.67V 740 479 370 221 130 54.7 32.7 21.6 11.0
1.70V 701 474 367 207 128 52.2 32.3 21.5 10.9
1.75V 697 473 364 201 125 51.0 32.0 21.2 10.6
1.80V 642 466 337 191 118 49.5 31.0 20.9 10.5
1.85V 582 442 306 179 111 48.0 30.0 20.5 10.3
SMU-C 12-120
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 923 591 451 271 156 67.5 39.3 26.0 13.7
1.67V 890 576 445 266 156 65.4 39.1 25.9 13.2
1.70V 844 570 441 249 153 62.5 38.6 25.4 13.0
1.75V 838 568 438 241 150 61.0 38.3 25.1 12.7
1.80V 772 560 406 230 141 59.2 37.1 24.7 12.4
1.85V 700 531 368 215 133 57.4 35.9 24.3 12.2
SMU-C 12-134
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 773 533 415 265 174 70.2 48.9 28.4 14.1
1.67V 733 527 411 260 168 70.2 48.9 28.0 14.1
1.70V 685 513 405 253 164 70.2 48.9 27.8 14.1
1.75V 638 480 381 247 163 69.1 48.4 27.3 14.0
1.80V 572 446 358 240 160 68.2 47.6 26.8 13.5
1.85V 458 370 312 220 158 67.9 46.9 26.3 12.7
SMU-C 12-90
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 643 412 314 189 118 50.9 29.6 19.6 10.3
1.67V 620 401 310 185 117 49.3 29.5 19.5 9.94
1.70V 588 397 307 173 115 47.1 29.1 19.4 9.81
1.75V 584 396 305 168 113 46.0 28.9 19.1 9.57
1.80V 538 390 283 160 107 44.7 28.0 18.9 9.49
1.85V 488 370 256 150 100 43.3 27.1 18.6 9.32
5.2 Discharge Data with Constant Power, continued
Wattage values for each battery model as a function of time and voltage with constant Watts per
cell @ 77°F/25°C
