19 745-680-B11-001, Rev. A
SMU-C 12-26
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 118 73.5 55.5 33.8 19.9 8.74 5.34 2.91 1.57
1.67V 111 69.7 53.4 32.4 19.6 8.40 5.23 2.88 1.52
1.70V 102 67.2 52.1 29.4 19.0 7.84 5.11 2.87 1.49
1.75V 99.6 65.1 50.4 27.9 18.1 7.58 5.00 2.86 1.45
1.80V 89.1 62.2 45.8 25.9 17.0 7.28 4.70 2.80 1.41
1.85V 78.7 59.2 41.2 23.8 15.8 7.02 4.41 2.76 1.38
SMU-C 12-28
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 118 73.5 55.5 33.8 19.9 8.74 5.34 2.91 1.57
1.67V 111 69.7 53.4 32.4 19.6 8.40 5.23 2.88 1.52
1.70V 102 67.2 52.1 29.4 19.0 7.84 5.11 2.87 1.49
1.75V 99.6 65.1 50.4 27.9 18.1 7.58 5.00 2.86 1.45
1.80V 89.1 62.2 45.8 25.9 17.0 7.28 4.70 2.80 1.41
1.85V 78.7 59.2 41.2 23.8 15.8 7.02 4.41 2.76 1.38
SMU-C 12-30
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 118 73.5 55.5 33.8 21.3 9.36 5.72 3.12 1.68
1.67V 111 69.7 53.4 32.4 21.0 9.00 5.60 3.09 1.62
1.70V 102 67.2 52.1 29.4 20.4 8.40 5.48 3.07 1.60
1.75V 99.6 65.1 50.4 27.9 19.4 8.12 5.36 3.06 1.56
1.80V 89.1 62.2 45.8 25.9 18.2 7.80 5.04 3.00 1.52
1.85V 78.7 59.2 41.2 23.8 17.0 7.52 4.72 2.96 1.47
SMU-C 12-35
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 165 103 77.6 47.4 24.9 10.9 6.67 3.63 1.96
1.67V 155 97.6 74.7 45.3 24.5 10.5 6.53 3.60 1.90
1.70V 142 94.1 72.9 41.2 23.8 9.80 6.39 3.59 1.87
1.75V 139 91.2 70.6 39.1 22.7 9.47 6.25 3.57 1.82
1.80V 125 87.1 64.1 36.2 21.2 9.10 5.88 3.50 1.77
1.85V 110 82.9 57.6 33.4 19.8 8.77 5.51 3.45 1.72
5.1 Discharge Data with Constant Current, continued
Amperage values for each battery model as a function of time and voltage @ 77°F/25°C.
