0 discharge specifications, 1 discharge data with constant current – Alpha Technologies AlphaCellTM SMU-C Series User Manual
Page 17
17
745-680-B11-001, Rev. A
SMU-C 6-12
End voltage 5Min
10Min 15Min 30Min 1h
3h
5h
10h
20h
1.60V
65.0
40.4
30.5
18.6
9.38
4.12
2.52
1.37
0.74
1.67V
61.0
38.4
29.3
17.8
9.26
3.96
2.46
1.36
0.71
1.70V
55.9
37.0
28.7
16.2
8.98
3.70
2.41
1.35
0.70
1.75V
54.8
35.8
27.7
15.4
8.55
3.57
2.36
1.35
0.69
1.80V
49.0
34.2
25.2
14.2
8.01
3.43
2.22
1.32
0.67
1.85V
43.3
32.6
22.6
13.1
7.46
3.31
2.08
1.30
0.65
5.1 Discharge Data with Constant Current
Amperage values for each battery model as a function of time and voltage @ 77°F/25°C.
5.0 Discharge Specifications
SMU-C 6-4.5
End voltage 5Min
10Min 15Min 30Min 1h
3h
5h
10h
20h
1.60V
17.6
10.9
8.25
5.03
3.20
1.40
0.86
0.47
0.25
1.67V
16.5
10.4
7.94
4.81
3.16
1.35
0.84
0.46
0.24
1.70V
15.1
10.0
7.75
4.38
3.06
1.26
0.82
0.46
0.24
1.75V
14.8
9.69
7.50
4.16
2.92
1.22
0.80
0.46
0.23
1.80V
13.3
9.25
6.81
3.85
2.73
1.17
0.76
0.45
0.23
1.85V
11.7
8.81
6.13
3.54
2.54
1.13
0.71
0.44
0.22
SMU-C 6-7
End voltage 5Min
10Min 15Min 30Min 1h
3h
5h
10h
20h
1.60V
39.0
24.3
18.3
11.2
5.69
2.50
1.53
0.83
0.45
1.67V
36.6
23.0
17.6
10.7
5.61
2.40
1.49
0.82
0.43
1.70V
33.5
22.2
17.2
9.71
5.44
2.24
1.46
0.82
0.43
1.75V
32.9
21.5
16.6
9.22
5.18
2.17
1.43
0.82
0.42
1.80V
29.4
20.5
15.1
8.54
4.85
2.08
1.34
0.80
0.41
1.85V
26.0
19.6
13.6
7.86
4.52
2.01
1.26
0.79
0.40
SMU-C 12-4.5
End voltage 5Min 10Min 15Min 30Min 1Hr
3Hr
5Hr
10Hr 20Hr
1.60V
17.6
10.9
8.25
5.03
3.20
1.40
0.86
0.47
0.25
1.67V
16.5
10.4
7.94
4.81
3.16
1.35
0.84
0.46
0.24
1.70V
15.1
10.0
7.75
4.38
3.06
1.26
0.82
0.46
0.24
1.75V
14.8
9.69
7.50
4.16
2.92
1.22
0.80
0.46
0.23
1.80V
13.3
9.25
6.81
3.85
2.73
1.17
0.76
0.45
0.23
1.85V
11.7
8.81
6.13
3.54
2.54
1.13
0.71
0.44
0.22
