745-680-B11-001, Rev. A 20
SMU-C 12-40
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 183 114 86.0 52.4 28.4 12.5 7.63 4.15 2.24
1.67V 172 108 82.7 50.1 28.1 12.0 7.47 4.11 2.17
1.70V 158 104 80.8 45.6 27.2 11.2 7.31 4.10 2.13
1.75V 154 101 78.2 43.3 25.9 10.8 7.15 4.08 2.08
1.80V 138 96.4 71.0 40.1 24.3 10.4 6.72 4.00 2.02
1.85V 122 91.8 63.8 36.9 22.6 10.0 6.29 3.95 1.98
SMU-C 12-55
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 236 147 111 67.6 39.8 17.5 10.7 5.71 3.09
1.67V 222 139 107 64.7 39.3 16.8 10.5 5.66 2.98
1.70V 203 134 104 58.8 38.1 15.7 10.2 5.63 2.93
1.75V 199 130 101 55.9 36.3 15.2 10.0 5.61 2.85
1.80V 178 124 91.6 51.8 34.0 14.6 9.41 5.50 2.78
1.85V 157 118 82.4 47.6 31.7 14.0 8.80 5.43 2.72
SMU-C 12-65
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 278 173 130 79.5 46.9 20.6 12.6 6.85 3.70
1.67V 261 164 125 76.0 46.3 19.8 12.3 6.79 3.57
1.70V 239 158 122 69.1 44.9 18.5 12.1 6.76 3.52
1.75V 234 153 118 65.7 42.8 17.9 11.8 6.74 3.43
1.80V 209 146 108 60.8 40.0 17.2 11.1 6.60 3.33
1.85V 185 139 96.8 56.0 37.3 16.5 10.4 6.51 3.26
SMU-C 12-75
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 319 199 150 91.3 54.0 23.7 14.5 7.89 4.26
1.67V 299 188 144 87.4 53.3 22.8 14.2 7.82 4.12
1.70V 274 182 141 79.4 51.7 21.3 13.9 7.78 4.05
1.75V 269 176 136 75.4 49.2 20.6 13.6 7.76 3.94
1.80V 241 168 124 69.9 46.1 19.8 12.8 7.60 3.84
1.85V 212 160 111 64.3 43.0 19.1 12.0 7.50 3.77
5.1 Discharge Data with Constant Current, continued
Amperage values for each battery model as a function of time and voltage @ 77°F/25°C.
