745-680-B11-001, Rev. A 22
SMU-C 12-150
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 656 408 308 188 109 48.0 29.4 16.0 8.64
1.67V 616 387 296 180 108 46.2 28.7 15.8 8.34
1.70V 564 373 289 163 105 43.1 28.1 15.8 8.21
1.75V 553 361 280 155 99.8 41.7 27.5 15.7 7.99
1.80V 495 345 254 144 93.4 40.0 25.9 15.4 7.78
1.85V 437 329 229 132 87.1 38.6 24.2 15.2 7.56
SMU-C 12-200
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 700 480 350 210 132 54.6 38.2 21.2 10.5
1.67V 630 438 340 204 132 54.4 37.8 20.9 10.5
1.70V 598 422 328 200 131 54.4 37.8 20.7 10.5
1.75V 532 390 310 196 130 54.0 37.5 20.4 10.5
1.80V 480 362 296 190 128 53.8 37.2 20.0 10.1
1.85V 364 298 256 175 127 53.6 36.9 19.7 9.48
5.1 Discharge Data with Constant Current, continued
Amperage values for each battery model as a function of time and voltage @ 77°F/25°C.
