21 745-680-B11-001, Rev. A
SMU-C 12-90
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 366 228 172 105 65.4 28.7 17.5 9.55 5.16
1.67V 344 216 165 100 64.5 27.6 17.2 9.46 4.98
1.70V 315 208 162 91.2 62.6 25.8 16.8 9.42 4.90
1.75V 309 202 156 86.6 59.6 24.9 16.4 9.39 4.78
1.80V 276 193 142 80.2 55.8 23.9 15.5 9.20 4.65
1.85V 244 184 128 73.9 52.0 23.1 14.5 9.07 4.54
SMU-C 12-100
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 437 272 205 125 72.5 31.8 19.4 10.6 5.72
1.67V 410 258 197 120 71.5 30.6 19.0 10.5 5.52
1.70V 376 249 193 109 69.4 28.6 18.6 10.4 5.44
1.75V 369 241 187 103 66.1 27.6 18.2 10.4 5.29
1.80V 330 230 169 95.8 61.9 26.5 17.1 10.2 5.15
1.85V 291 219 152 88.1 57.7 25.6 16.0 10.1 5.01
SMU-C 12-120
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 526 327 247 151 86.7 38.1 23.3 12.7 6.85
1.67V 494 310 237 144 85.6 36.6 22.8 12.5 6.61
1.70V 452 299 232 131 83.0 34.2 22.3 12.5 6.50
1.75V 443 290 224 124 79.1 33.0 21.8 12.4 6.33
1.80V 397 277 204 115 74.0 31.7 20.5 12.2 6.16
1.85V 350 264 183 106 69.0 30.6 19.2 12.0 6.03
SMU-C 12-134
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 469 322 235 141 88.4 36.6 25.6 14.2 7.06
1.67V 422 293 228 137 88.3 36.4 25.4 14.0 7.04
1.70V 401 283 220 134 88.0 36.4 25.4 13.9 7.04
1.75V 356 261 208 131 87.1 36.2 25.2 13.6 7.00
1.80V 322 243 198 127 86.0 36.0 24.9 13.4 6.76
1.85V 244 200 172 117 85.1 35.9 24.7 13.2 6.35
5.1 Discharge Data with Constant Current, continued
Amperage values for each battery model as a function of time and voltage @ 77°F/25°C.
