745-680-B11-001, Rev. A 18
5.1 Discharge Data with Constant Current, continued
Amperage values for each battery model as a function of time and voltage @ 77°F/25°C.
SMU-C 12-7
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 39.0 24.3 18.3 11.2 5.69 2.50 1.53 0.83 0.45
1.67V 36.6 23.0 17.6 10.7 5.61 2.40 1.49 0.82 0.43
1.70V 33.5 22.2 17.2 9.71 5.44 2.24 1.46 0.82 0.43
1.75V 32.9 21.5 16.6 9.22 5.18 2.17 1.43 0.82 0.42
1.80V 29.4 20.5 15.1 8.54 4.85 2.08 1.34 0.80 0.41
1.85V 26.0 19.6 13.6 7.86 4.52 2.01 1.26 0.79 0.40
SMU-C 12-12
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 65.0 40.4 30.5 18.6 9.38 4.12 2.52 1.37 0.74
1.67V 61.0 38.4 29.3 17.8 9.26 3.96 2.46 1.36 0.71
1.70V 55.9 37.0 28.7 16.2 8.98 3.70 2.41 1.35 0.70
1.75V 54.8 35.8 27.7 15.4 8.55 3.57 2.36 1.35 0.69
1.80V 49.0 34.2 25.2 14.2 8.01 3.43 2.22 1.32 0.67
1.85V 43.3 32.6 22.6 13.1 7.46 3.31 2.08 1.30 0.65
SMU-C 12-14
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 67.4 41.9 31.6 19.3 9.81 4.31 2.63 1.43 0.77
1.67V 63.2 39.8 30.4 18.4 9.68 4.14 2.58 1.42 0.75
1.70V 57.9 38.3 29.7 16.8 9.38 3.86 2.52 1.41 0.74
1.75V 56.8 37.1 28.7 15.9 8.94 3.74 2.47 1.41 0.72
1.80V 50.8 35.4 26.1 14.8 8.37 3.59 2.32 1.38 0.70
1.85V 44.8 33.8 23.5 13.6 7.80 3.46 2.17 1.36 0.68
SMU-C 12-18
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 88.6 55.1 41.6 25.4 14.2 6.24 3.81 2.08 1.12
1.67V 83.2 52.3 40.0 24.3 14.0 6.00 3.73 2.06 1.08
1.70V 76.2 50.4 39.1 22.1 13.6 5.60 3.65 2.05 1.07
1.75V 74.7 48.8 37.8 21.0 13.0 5.41 3.57 2.04 1.04
1.80V 66.9 46.6 34.3 19.4 12.1 5.20 3.36 2.00 1.01
1.85V 59.0 44.4 30.9 17.9 11.3 5.01 3.15 1.97 1.00
