745-680-B11-001, Rev. A 26
SMU-C 12-40
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 321 206 157 94.4 51.3 22.1 12.9 8.53 4.48
1.67V 310 201 155 92.5 51.0 21.4 12.8 8.48 4.32
1.70V 294 199 154 86.6 50.0 20.5 12.7 8.43 4.27
1.75V 292 198 152 84.0 49.2 20.0 12.6 8.32 4.16
1.80V 269 195 141 80.1 46.3 19.4 12.2 8.07 4.05
1.85V 244 185 128 75.0 43.6 18.8 11.8 7.98 4.00
SMU-C 12-55
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 415 266 203 122 71.8 31.0 18.0 11.7 6.00
1.67V 400 259 200 119 71.4 30.0 18.0 11.6 5.91
1.70V 379 256 198 112 70.0 28.7 17.7 11.5 5.82
1.75V 377 255 197 108 68.8 28.0 17.6 11.3 5.70
1.80V 347 252 182 103 64.9 27.2 17.0 11.2 5.62
1.85V 315 239 165 96.8 61.0 26.4 16.5 11.0 5.53
SMU-C 12-65
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 487 312 238 143 84.7 36.5 21.3 13.9 7.28
1.67V 470 304 235 140 84.1 35.4 21.2 13.8 7.02
1.70V 446 301 233 131 82.5 33.8 20.9 13.7 6.93
1.75V 443 300 231 127 81.1 33.0 20.7 13.5 6.76
1.80V 408 296 214 121 76.5 32.0 20.1 13.3 6.67
1.85V 370 281 194 114 71.9 31.1 19.4 13.2 6.62
SMU-C 12-75
End voltage 5Min 10Min 15Min 30Min 1Hr 3Hr 5Hr 10Hr 20Hr
1.60V 560 358 273 164 97.5 42.1 24.5 16.0 8.40
1.67V 540 349 270 161 96.9 40.7 24.4 15.9 8.10
1.70V 512 346 268 151 95.1 38.9 24.1 15.8 8.00
1.75V 502 345 265 146 93.4 38.0 23.9 15.6 7.90
1.80V 468 340 246 140 88.1 36.9 23.1 15.4 7.72
1.85V 425 322 223 131 82.8 35.8 22.4 15.2 7.62
5.2 Discharge Data with Constant Power, continued
Wattage values for each battery model as a function of time and voltage with constant Watts per
cell @ 77°F/25°C
