19 016-559-B0-001 Rev. A
2.0 Installation, continued
2.9 Specifi cations
Specifi cations
Electrical
Input Voltage 45-65Vac 60Hz / 65-90Vac 60 Hz
Input Current 10 Amps RMS (max)
Output Voltage 63Vac 60Hz / 87Vac 60Hz
Output Current <8 Amps RMS (max)
Output Rating 650 VA (max)
Overload Protections 115% for 27 minutes
Short Circuit Bypass mode, automatic recovery
Overload Recovery Automatic
Surge Resistance 6kV/3000A (IEEE C61.45 part 15)
Effi ciency >96% at 25 to 100 percent load
RF Freq Range 5MHz to 1000MHz
RF Insertion Loss
Maximum 1.2 dB (5MHz to 50MHz)
1.2 dB (50MHz to 870MHz)
1.6 dB (870MHz to 1000MHz)
Flatness ±0.25 dB (5MHz to 50MHz)
±0.35 dB (50MHz to 870MHz)
±0.50 dB (870MHz to 1000MHz)
RF Slope Maximum 0.80dB (5MHz to 50MHz)
-1.0dB (50MHz to 870MHz), -1.25dB (870MHz to 1000MHz)
Hum Modulation < -68 dB (5MHz to 1000MHz)(< -82 dB freq. domain)
Return Loss Minimum 17 dB (5MHz to 1000MHz)
Electrical Egress <-120dBm (45MHz to 870MHz)
Isolation Neutral carries through
Environmental
Operating Temperature -40°F to 149°F (-40°C to 65°C)
Storage Temperature -58°F to 158°F (-50°C to 70°C)
Outdoor Rating Type 4 Enclosure
Standard Compliance
Safety CSA (C/US)
CAN/CSA C22.2 No. 60950-1-07
UL 60950-1, 2nd Edition
Standard Features
High-effi ciency autotransformer
Intelligent overload protection
Water-tight enclosure; wall or strand mounted
