2 pwe enclosure diagram – Alpha Technologies PME Series User Manual
Page 11

11
031-161-B0-006, Rev. F
1.0 Introduction,
continued
1.2 PWE Enclosure Diagram
Knockouts
for Status Monitoring
Optional SPI
Locations
Standard SPI
Location
External Ground Lug
Standard LRI Location
(optional knockout located on right side)
Optional ACI Location
(knockouts located on left and
right sides of enclosure)
Optional External Breaker Box
Front View
Rear View
Fig. 1-3, PWE-3 Enclosure (confi gurations may vary)
Optional
Cooling Fan
Optional SPI
Standard SPI
Location
Optional Duplex
Receptacle
Generator
Access Door
Optional Battery
Slide Tray Assembly
Power Supply Module Shelf
Optional Battery Integration Tray
ACI
LRI
