4 natural gas meter confi gurations, 0 site preparation, continued – Alpha Technologies AlphaGen PN-6x-T 7.5kW 48VDC - Installation and Operation Manual User Manual
Page 23
745-020-B0-003, Rev. C
23
Fig. 2-6, Remote Natural Gas Meter Setup
2.0
Site Preparation, continued
2.4 Natural Gas Meter Confi gurations
The gas utility should have the meter installed prior to generator arrival. Meter confi gurations
must comply with local codes. The illustrations provided are for illustrative purposes only.
Fig. 2-5, Collocated Natural Gas Meter Setup
METER
GAS
NATURAL
STREET PRESSURE
METERED SUPPLY
MANUAL SHUTOFF
STREET REGULATOR
Optional high pressure
excess flow valve
REQUIRED IF METER
CANNOT BE SEEN
MANUAL SHUTOFF
METER
GAS
NATURAL
STREET PRESSURE
MANUAL SHUTOFF
STREET REGULATOR
OPTIONAL HIGH PRESSURE
EXCESS FLOW VALVE
