FBE Enclosure Cooling
Part Name
Part Number
Ice Qube IQI000V 120Vac 60Hz Alarm
040-020-10-001
Ice Qube IQ2400VXS 120Vac 60Hz Alarm
040-021-10-001
48Vdc Fan Panel
746- 184-20
24Vdc Fan Panel
746-184-21
120Vac Fan Panel
746-184-22
24Vdc Heat Exchanger
040-025-12-001
48Vdc Heat Exchanger
040-025-13-001
Insulation Kit 1" (For Air Conditioner Configurations)
746-201-20
48Vdc Fan Control Board
746-098-20
24Vdc Fan Control Board
746 -098-21
48Vdc Overtemp Exhaustl Kit
746-224-20
24Vdc Overtemp Exhaust Kit
746-224-21
Cordex Assembly Parts
Part Name
Part Number
Cordex Assembly
030-834-20-A002
Cordex Power Module 48-1.2kW
010-619-20-A001
1.0 Introduction, continued
1.5
FBE2322 Parts Tables, continued
Table 1-4, FBE2322 Parts Table, continued
Cordex Plug-in Breakers w/
Auxiliary Switch
Part Number
Cordex Plug-in Breakers w/
Auxiliary Switch
Part Number
1 Amp
470-300-10-A000
40 Amp
470-309-10-A000
3 Amp
470-301-10-A000
45 Amp
470-310-10-A000
5 Amp
470-302-10-A000
50 Amp
470-311-10-A000
10 Amp
470-303-10-A000
60 Amp
470-312-10-A000
15 Amp
470-304-10-A000
70 Amp
470-313-10-A000
20 Amp
470-305-10-A000
80 Amp
470-314-10-A000
25 Amp
470-306-10-A000
90 Amp
470-315-10-A000
30 Amp
470-307-10-A000
100 Amp
470-316-10-A000
35 Amp
470-308-10-A000
FBE GMT Fuse Options
Part Name
Part Number
Part Name
Part Number
GMT Fuse 1/2 AMP
460-004-10
GMT Fuse 4 AMP
460-085-10
GMT Fuse 1 AMP
460-006-10
GMT Fuse 5 AMP
460-084-10
GMT Fuse 1-1/3 AMP
460-081-10
GMT Fuse 7-1/2 AMP
460-105-10
GMT Fuse 2 AMP
460-083-10
GMT Fuse 10 AMP
460-069-10
GMT Fuse 3 AMP
460-013-10
GMT Fuse 15 AMP
460-150-10
FBE Battery Accessories
Part Name
Part Number
Battery Cable Kit #6AWG/100A Fuse
746-164-20
Battery Tray 19", Rack Mount Kit
746-200-20
Fuse, 100A
460-191-10
