ABUS FU2938 Compact Alerting User Manual
Page 7
7
Verdrahtung der Kompaktalarmierung FU2938 (Funkvariante)
1. Führen Sie das Anschlusskabel vom Funk-Universalmodul mit dem RJ-
11 Stecker rückseitig in das Gehäuse ein.
2. Stecken Sie den RJ-11 Stecker in die auf der Hauptplatine vorgesehene
Buchse.
3. Setzen Sie den Jumper (12), je nach Position der Steckbrücke sind
die Diagnose-
LED’s aktiv oder deaktiv.
4. Weitere Einstellungen sind nicht vorzunehmen.
