ABUS FU2938 Compact Alerting User Manual
Page 27
27
Câblage du système d’alarme compact FU2938 (variante radio)
1. Introduisez le câble de raccordement de la module universelle radio
avec la prise RJ-11 du revers dans le boîtier.
2. Insérez la prise RJ-11 dans la boîte prévue sur la platine principale.
3. Réglez le cavalier (12), selon la position des ponts enfichables les LEDs
de diagnose sont actifs ou non-actifs.
4.
D’autres ajustages ne sont pas opérables.
