Download Wiring Diagram from website:
( www.cla-val.com )
Electrical Specifications
Electrical Power:
• 24 VDC, 6 / 10 / 15 rpm / sizes
300 mA max. load draw
85 mA stand-by (no load draw)
Power Protection:
• Max. 32 VDC over voltage
Max. 1000 mA torque load
Reverse polarity & short circuit
80°C stop @ high temperature
Led Display:
• Green LED
Electrical Connection:
• 2 x Moulded 10 m cables
Power Supply:
• 24 VDC +/- 10%, min. 20 mA, normal 60 mA, max. 1 A
Input Command:
• 4-20 mA (2 wires)
• 2 x dry contact (manual positioning)
Input 4-20 mA Protection:
• Max. 32 VDC over voltage
Optocoupler isolation @ CMR 100 V
(CMR: common mode rejection)
Insulated (2 wires)
Output feedback:
• 4-20 mA (Output charge ≤ 500 Ω
• 2 x programmable position alarms
Output 4-20 mA Protection:
• Max. 32 VDC over voltage
(The input dry contact and 4-20 mA output have the
same common or earth but are not individually
Isolated
Other Specifications
Operating Pressure: PN 16 bar standard
Operation Type: Continuous Control
Operating Temperature Range: -10°C to +80°C
Protection: IP68 standard allowing full immersion
(solenoid, junction box, sensor, not
included in IP68)
Interface: Plug & Play / NT / 2000 / XP / Vista
Default Mode
Troubleshooting:
Refer to user manual for Led diagnostics
(red-green-blinking)
Remote Command Failure:
Options available: maintain current position, go to
4 mA position, go to 20 mA position
