Energy – Gotham 10 AF Cross Baffle SpecSheet User Manual
Page 2
© 2005-2014 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 01/21/14. Specifications subject to change without notice.
PAGE 2 OF 3
AF-10-XBAFFLE-TRT
DIM
EN
SIO
N
AL D
AT
A
EL
EC
TR
IC
AL
N
OT
ES
10” AF
Cross Baffle
Horizontal Lamp, Triple-Tube
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
ORDERING NOTES
1.
For use with Sylvania or Philips lamps only.
2.
Multi-volt electronic ballast capable of operating on any voltage from 120V
through 277V, 50 or 60 Hz.
3.
Not available with 57W.
4.
Available in 120V or 277V only.
5.
6.
For compatible RELOC systems, refer to
7.
Not available with emergency options.
8.
Must specify wattage. Ex.: WRL32
Aperture: 9-3/4 (24.8)
Ceiling Opening: 10-1/2 (26.7)
Overlap Trim: 11-1/8 (28.3)
Lens recess: 5-1/2 (14.0)
978 [25.1]
17 3
16 [43.7]
15 9
16 [39.5]
Energy
(Calculated in accordance with NEMA Standard LE-5)
ANNUAL
*
LAMP
LAMP
BALLAST INPUT
LER.DOL
ENERGY
COST
DESCRIPTION
LUMENS
FACTOR WATTS
35
$6.89
2/42TRT
6400
0.98
90
* Comparative yearly lighting energy cost per 1,000 lumens
