AF-8-DEcO
AF 2/32TRT 8AR DLD (2) CF32TRT, 2400 LUMENS PER LAMP, 1.2 S/MH, TEST NO. LTL19816
AF 2/32TRT 8AR DLR (2) CF32TRT, 2400 LUMENS PER LAMP, 1.3 S/MH, TEST NO. LTL19815
AF 2/42TRT 8AR DLD (2) CF42TRT, 3200 LUMENS PER LAMP, 1.2 S/MH, TEST NO. LTL19814
AF 2/42TRT 8AR DLR (2) CF42TRT, 3200 LUMENS PER LAMP, 1.3 S/MH, TEST NO. LTL19813
PH
OTO
M
ET
RY
Distribution Curve Distribution Data Output Data Coefficient of Utilization Illuminance: Single Luminaire 30” Above Floor
8” AF
Drop Luminous Ring/Disk
Horizontal Lamp, Double Twin-Tube or Triple-Tube
PHOTOMETRY NOTES
• Tested to current IES and NEMA standards under stabilized laboratory conditions.
• Actual performance may differ as a result of end-user environment and application.
• Consult factory or IES file for microgroove baffle, black cone or other photometric reports.
