Gotham 4 SQDLWH Lensed Wallwash SpecSheet User Manual
Page 2
©2009-2013 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 01/29/13. Specifications subject to change without notice.
PAGE 2 OF 4
SQDLWH-4-WSH
4” SQDLWH
Lensed Wallwash
PAR Lamp
All dimensions are inches (centimeters) unless otherwise noted.
PH
OTO
M
ET
RY
Ceiling opening:
5-1/8 (13.0)
Overlap trim:
5-3/4 (14.6)
Aperture opening: 4-3/8 (11.1)
9-7/8
(25.0)
15-1/4
(38.9)
17-3/16
(43.7)
DIM
EN
SIO
N
AL D
AT
A
