CHL-8-LEnSEd
8” CHL
Enclosed Wet Location Cylinder
Metal Halide, 6” Aperture
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
DIM
EN
SIO
N
AL D
AT
A
Aperture: 6-1/4 (15.9)
Housing Diameter: 7-5/8 (19.4)
Housing Height: 17-3/8 (44.1)
A
B
C
A: 8-5/32 (20.7)
B: 17-3/8 (44.1)
C: 7-5/8 (19.4)
D: 3-1/8 (7.9)
D
Wall Mount Bracket
Clearance holes
for 3/8" (.95)
anchors
3-3/8
(8.6)
CHL8 WM
3-3/8
(8.6)
