AFW-10-OPEN-TRT
Gotham Architectural Downlighting
Compact Fluorescent Downlights
10” AFW
Open Wallwash
Horizontal Lamp
Triple-Tube
FE
AT
U
RE
S
OR
DER
ING
IN
FO
RM
AT
ION
OPTICAL SYSTEM
•
Self-flanged, semi-specular or matte-diffuse reflector. Fluted vertical upper
section works in conjunction with patented Bounding Ray™ Optical Principle to
provide lamp before lamp image and smooth transition from top of reflector to
bottom. Hybrid kicker reflector for wallwash. Minimum flange matches reflector
finish. White painted flange optional.
•
Hybrid kicker reflector has highly specular finish on bottom 3/4” and transitions
to diffuse on the rest of the kicker reflector.
•
Hinged lampdoor seals upper trim for optimal fixture efficiency and the reduc-
tion of stray light in the plenum.
MECHANICAL SYSTEM
•
16-gauge galvanized steel mounting/plaster frame with integral yoke to retain
optical system. Maximum 1-1/2” ceiling thickness.
•
16-gauge galvanized steel mounting bars with continuous 4” vertical adjust-
ment are shipped pre-installed. Post-installation adjustment possible without
the use of tools from above or below the ceiling.
•
Galvanized steel junction box with bottom-hinged access covers and spring
latches. Two combination 1/2”–3/4” and three 1/2” knockouts for straight-
through conduit runs. Capacity: 8 (4 in, 4 out) No. 12 AWG conductors, rated
for 90°C.
ELECTRICAL SYSTEM
•
Horizontally mounted, four-pin, positive-latch, thermoplastic socket(s).
•
Class P, thermally protected high-power-factor electronic ballast(s) mounted to
the junction box (CP and EL ballast mounted on ballast tray).
•
SIMPLY5™ technology available.
LISTING
•
Fixtures are UL listed for thru-branch wiring, recessed mounting and damp
locations. Listed and labeled to comply with Canadian standards (see Options).
WARRANTY
•
1-year limited warranty. Complete warranty terms located at
www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
EXAMPLE: AFW 3/42TRT 10AR MVOLT
Series
Wattage/Lamp Aperture/Trim color
Finish
Lens type
Voltage
Ballast
AFW
1/18TRT
1/26TRT
1/32TRT
1/42TRT
1/57TRT
1
2/18TRT
2/26TRT
2/32TRT
2/42TRT
2/57TRT
1
3/18TRT
3/26TRT
3/32TRT
3/42TRT
10AR
Clear
10PR
Pewter
10WTR
Wheat
10CR
2
Champagne
gold
10GR
2
Gold
(blank) Semi-specular
LD
Matte-diffuse
(blank)
No lens
CGL
Clear glass lens
PCL
Clear polycarbonate
lens
MVOLT
3
120
277
347
(blank)
GEB10 standard. Electronic ballast.
Requires four-pin lamp
ECOS
3, 4
Lutron
®
EcoSystem
®
electronic
dimming ballast. Minimum dimming
level 5%
ADEZ
5
Advance Mark 10
®
electronic dim-
ming ballast. Minimum dimming
level 5%
ADZT
5
Advance Mark 7
®
electronic dimming
ballast. Minimum dimming level 5%
Options
WLP
3500 K lamp (shipped separately)
TRW
White painted flange
ELR
5,6
Emergency battery pack with remote test switch
GMF
5
Single, slow-blow fuse (not available with MVOLT)
RIF
Radio Interference Filter
RRL
7
RELOC
®
-ready luminaire. Provides compatibility with Lithonia RELOC
system. Access above ceiling required.
HW
Hardwire for S5 system; replaces RELOC
®
QDS
8
Quick disconnect for easy ballast replacement
CWW
Corner wallwash
DWW
Double wallwash
CP
8
Chicago plenum (consult factory)
CSA
CSA certified
NEPP
Interface for Sensor Switch
®
nLight
®
network with integral power supply. Refer to
WRL
9
Wattage restriction label
WL
Wet location; lens required
