© 2003-2014 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 01/08/14. Specifications subject to change without notice.
PAGE 3 OF 4
AFW-10-OPEN-TRT
PH
OTO
M
ET
RY
PHOTOMETRY NOTES
•
Tested to current IES and NEMA standards under stabilized laboratory conditions.
•
Actual performance may differ as a result of end-user environment and application.
•
Consult factory or IES file for microgroove baffle, black cone or other photometric reports.
Fixture/Lamp
Candlepower Data
Footcandle values
TECHNICAL INFORMATION
Footcandle values are initial and tables are based on minimum of six units. For fixture-to-wall
distance other than those shown, use maximum of one-to-one spacing (distance between fixtures not
more than distance to wall) for best results.
room
wall
90
0
112
0
1 2
135
0
157
0
1 2
67
0
1 2
45
0
22
0
1 2
10” AFW
Open Wallwash
Horizontal Lamp, Triple-Tube
AFW 2/32TRT 10AR
(2) CF32DT/E/IN/835 lamp
2400 total rated lumens
Test no. LTL9680
Vertical
Plane angle
angle
Room side
Wall side
Room 157½° 135° 112½° 90°
67½° 45° 22½° Wall
0° 1223 1223 1223 1223 1223
1223 1223 1223 1223
5° 1662 1581 1453 1330 1261
1247 1304 1331 1333
15° 2091 2112 1959 1623 1402
1433 1471 1371 1307
25° 1951 1980 1984 1772 1490
1426 1412 1250 1131
35° 1555 1536 1450 1291 1096
1069 1181 1188 1199
45°
971 951 899 799 687
765 970 1076 1124
55°
49 50 45 39 50
223 495 640 717
65°
10 10 10 10 19
100 230 283 288
75°
5
5
5
5
7
33 77 90 98
85°
0
0
1
1
1
3
6
8
12
95°
0
0
0
0
0
0
0
0
0
Luminaire 3' from wall
Luminaire 3' from wall
on 3' centers
on 4' centers
1
19 16 19
16 11 7
2
55 48 56
46 32 21
3
67 69 68
54 49 33
4
58 56 59
42 43 35
5
40 44 42
33 33 27
6
31 34 33
24 26 21
7
25 26 27
19 22 17
8
19 21 21
16 17 15
9
16 17 17
13 14 12
10
13 14 14
11 11 10
AFW 2/42TRT 10AR
(2) CF42DT/E/IN/835 lamp
3200 total rated lumens
Test no. LTL9681
Vertical
Plane angle
angle
Room side
Wall side
Room 157½° 135° 112½° 90°
67½° 45° 22½° Wall
0° 1555 1555 1555 1555 1555
1555 1555 1555 1555
5° 2017 1948 1840 1693 1580
1548 1587 1621 1624
15° 2523 2587 2395 2059 1728
1704 1756 1708 1648
25° 2242 2328 2346 2157 1740
1676 1711 1559 1439
35° 1398 1453 1440 1357 1358
1643 1834 1937 1963
45° 1140 1105 1029 933 752
881 1109 1261 1306
55°
59 64 60 54 63
277 585 781 883
65°
13 13 13 13 25
128 283 350 361
75°
8
8
8
8
10
44 98 113 121
85°
0
1
2
2
3
6
9
11 15
95°
0
0
0
0
0
0
0
0
0
Luminaire 3' from wall
Luminaire 3' from wall
on 3' centers
on 4' centers
1
23 20 23
20 13 9
2
68 59 69
58 39 26
3
78 83 79
63 58 39
4
67 68 68
49 52 41
5
48 54 50
39 41 33
6
39 42 41
29 33 27
7
31 32 34
24 26 21
8
24 26 26
20 21 18
9
20 21 21
16 17 14
10
16 17 17
13 14 12
AFW 3/32TRT 10AR
(3) CF32DT/E/IN/835 lamp
2400 total rated lumens
Test no. LTL9677
Vertical
Plane angle
angle
Room side
Wall side
Room 157½° 135° 112½° 90°
67½° 45° 22½° Wall
0° 1829 1829 1829 1829 1829
1829 1829 1829 1829
5° 2008 2022 2014 1928 1827
1782 1762 1722 1709
15° 2499 2427 2355 2200 1977
1835 1722 1741 1731
25° 2508 2415 2259 2069 1788
1735 1675 1678 1630
35° 1781 1757 1685 1547 1318
1262 1381 1492 1574
45°
982 969 925 857 721
709 945 1175 1332
55°
65 72 64 61 79
283 499 693 758
65°
11 11 11 12 31
164 279 316 321
75°
7
6
6
7
11
60 99 111 119
85°
0
0
1
1
2
9
14 11 17
95°
0
0
0
0
0
0
0
0
0
Luminaire 3' from wall
Luminaire 3' from wall
on 3' centers
on 4' centers
1
22 20 23
19 13 19
2
61 55 62
51 37 51
3
75 72 77
63 48 64
4
65 65 66
49 48 50
5
50 53 52
40 40 41
6
39 41 41
30 32 31
7
31 32 33
24 25 25
8
24 26 26
20 20 21
9
19 21 21
16 17 17
10
16 17 17
13 14 14
