Gotham 6 Evo Flangeless SpecSheet User Manual
Page 2
WATTAGE CONSUMPTION MATRIX
LUMENS
WATTAGE
LUMENS per WATT
2200
32
67
1800
28
66
1400
25
63
1000
18
61
© 2010-2013 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 10/09/13. Specifications subject to change without notice.
PAGE 2 OF 3
EVO-FL-6
DIM
EN
SIO
N
AL D
AT
A
EL
EC
TR
IC
AL
6” EVO
Flangeless
Solid-State Lighting
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
Aperture: 6-1/4 (15.9)
Ceiling Opening: 7-1/4 (18.4)
6 9
16 [16.7]
15 78 [40.3]
15 1
16 [38.3]
738 [18.7]
