Gotham 6 Evo Flangeless SpecSheet User Manual
6” evo
Luminaire Type:
Catalog Number
(autopopulated):
© 2010-2013 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 10/09/13. Specifications subject to change without notice.
PAGE 1 OF 3
EVO-FL-6
Gotham Architectural Downlighting
LED Downlights
6” Evo
®
Flangeless
Solid-State Lighting
FE
AT
U
RE
S
OR
DER
ING
IN
FO
RM
AT
ION
N
OT
ES
OPTICAL SYSTEM
•
Semi-specular, matte-diffuse or specular lower reflector
•
Patented Bounding Ray™ optical design (U.S. Patent No. 5,800,050)
•
45° cutoff to source and source image
•
Top-down flash characteristic
•
Lens composed of 92% transmissive holographic film integral to light engine
MECHANICAL SYSTEM
•
16-gauge galvanized steel construction; maximum 1-1/2” ceiling thickness
•
Telescopic mounting bars maximum of 32” and minimum of 15”, preinstalled,
4” vertical adjustment
•
Toolless adjustments post installation
•
Junction box capacity: 8 (4 in, 4 out ) 12AWG rated for 90°C
•
Light engine and driver accessible through aperture
ELECTRICAL SYSTEM
•
Fully serviceable and upgradeable LED light engine
•
70% lumen maintenance at 60,000 hours based on IESNA LM-79-2008
•
120-277VAC, 50/60hz power supply with 0-10V dimming (10-100%); rated for
50,000-hour life
•
Overload and short circuit protected
LISTINGS
•
Fixtures are CSA certified to meet US and Canadian standards; wet location,
covered ceiling
WARRANTY
•
5-year limited warranty. Complete warranty terms located at:
www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
ORDERING NOTES
1.
Not available with finishes.
2.
3.
Not available with NEPP option.
4.
120V only.
5.
6.
7.
Must specify 120 or 277V.
8.
Not available with EL or ELR options.
EXAMPLE: EVO 35/10 6ARFL 120
Series
Color temperature
Nominal lumen values
Aperture/Trim color
Trim style
Distribution
Finish
EVO
27/
2700 K
30/
3000 K
35/
3500 K
41/
4100 K
10
1000 lumens
14
1400 lumens
18
1800 lumens
22
2200 lumens
6AR
Clear
6PR
Pewter
6WTR
Wheat
6GR
Gold
6WR
1
White
6BR
1
Black
FL
Flangeless
(blank)
1.0 s/mh
VND
Very narrow (0.5
s/mh)
ND
Narrow (0.6 s/mh)
MD
Medium (0.8 s/mh)
WD
Wide (1.2 s/mh)
(blank)
Semi-specular
LD
Matte diffuse
LS
Specular
Voltage
Driver
Options
MVOLT
120
277
347
(blank)
2
0-10V dimming driver. Minimum dimming level 10%
ECOS2
2,3,4
Lutron
®
Hi-Lume
®
2-wire forward-phase dimming
driver. Minimum dimming level 1%
ECOS3
2,3
Lutron
®
Hi-Lume
®
3-wire or EcoSystem
®
dimming
driver. Minimum dimming level 1%
SF
Single fuse
RRL
RELOC
®
-ready luminaire. Provides compatibility with
Lithonia RELOC system. Access above ceiling required.
NEPP
Interface for Sensor Switch
®
nLight
®
network with
integral power supply
NSD
5
Sensor Switch
®
nLight
®
dimming relay
EL
6,7
Emergency battery pack
with integral test switch
ELR
6,7
Emergency battery pack
with remote test switch
CP
8
Chicago plenum
BGTD
Bodine generator trans-
fer device
ACCESSORIES order as separate catalog numbers (shipped separately)
CTA4-8 YK
Ceiling thickness adapter (extends mounting frame to accommodate ceiling thickness up to 2”).
ISD BC
0-10V wallbox dimmer
