VN-QUANTUM User Guide Section 1: Installation & Setup
I455GB issue 8 Page 21
Fitting a Mains Plug
If you are fitting a plug to the unterminated power cord (or replacing an existing plug),
the plug MUST:
•
be rated for use with mains voltage
•
be equipped with a grounding pin/connection
•
comply with any applicable National or Local electrical regulations.
•
be fitted with a correctly rated fuse (applicable to UK-style plugs only – see page 22.)
WARNING: Never attempt to fit or use a plug without a grounding or earthing pin/connection.
Wiring Details
The wires of both mains power cords (supplied with each VN-QUANTUM Processor) are color-coded
as shown in the table below; be sure to connect your plug in accordance with the
following guidelines:
Connect the wire
colored... to the plug terminal identified
with...
Brown ‘L’ or ‘Live’ or ‘Line’
(or colored red or brown)
Blue ‘N’ or ‘Neutral’
(or colored blue or black)
Green & Yellow ‘ ’ or ‘E’ or ‘Earth’ or ‘Ground’
(or colored green or green & yellow)
WARNING — If you are unsure of the connections,
or if the markings in your plug do not match those
given above,
CONSULT A QUALIFIED ELECTRICIAN.
WARNING: THIS EQUIPMENT MUST BE GROUNDED / EARTHED.
