VSW 2VGA A • Installation and Operation 2-19
12 V Power
Supply
VSW 2VGA A
INPUT 1
2
1
INPUT 2
VSW 2VGA A
Projector
A
B B
Input 1
Out
Input 2
VSW 2VGA A
INPUT 1
2
1
INPUT 2
VSW 2VGA A
INPUT 1
2
1
INPUT 2
1 2 3 4
Out Out
VSW I AAP
VSW I AAP COMPUTER AUDIO
SHOW ME
VSW I AAP
VSW I AAP COMPUTER AUDIO
SHOW ME
VSW I AAP
VSW I AAP COMPUTER AUDIO
SHOW ME
VSW I AAP
VSW I AAP COMPUTER AUDIO
SHOW ME
Out
Jumper
Internal Jumper Settings
JMP1
JMP3
JMP4
JMP5
JMP6
Setting
Closed
Closed
Closed
Closed
Closed
Jumper
JMP1
JMP3
JMP4
JMP5
JMP6
Setting
Closed
Closed
Closed
Open
Open
12 V Power
Supply*
Input 1 Input 2
Input 1 Input 2
* Every switcher connected
to Input 1 of another
switcher must have its
own power supply.
A B
Figure 2-15 — Tree configuration
