Installation Overview

To install and set up the SW2/SW4 switcher,

1

Mount the switcher on a rack shelf or furniture, if desired.

2

Connect input source(s) to one or more SW2/SW4 video

input connectors.

3

Connect an output device to the SW2/SW4 output

connector.

4

Connect the audio connectors of your input device(s) to

the SW2/SW4 audio input 3.5 mm TRS mini jacks.

5

Wire one of the provided 5-pole captive screw plugs to

your audio output cable, and connect your output device’s

audio input to the SW2/SW4 captive screw audio output

connector.

6

Insert the other provided captive screw plug into the

Remote/Auto-sw connector on the SW2/SW4 rear panel.

Wire your RS-232 cable to pins 1, 2, and 3 of this plug, and

connect the other end of the cable to your computer. (See

"Wiring for RS-232," later in this chapter.)

7

If using autoswitching, jumper-connect together pins 4

and 5 of the 5-pin captive screw plug that you plugged

into the Remote/Auto-Sw connector in step

6

. (See

“Enabling autoswitching,” later in this chapter.)

8

If necessary, wire the provided 2-pin captive screw

connector to the external power supply. (See “Wiring the

Power Connector,” later in this chapter.)

9

Power on the output display.

10

Apply power to the switcher.

11

Power on the input device(s).

Mounting the SW DVI A Series

The SW DVI A Series switcher can be set on a table, mounted on

a rack shelf, or mounted under a desk, podium, or table.

Tabletop use

Four self-adhesive rubber feet are included with the SW2/SW4.

For tabletop use, attach one foot at each corner on the bottom of

the unit, and place the switcher in the desired location.

Rack mounting

For optional rack mounting, do not install the rubber feet.

Mount the switcher on any of the following rack shelves:

RSB 123 1U

, 3.5" Deep VersaTools

®

Basic Rack Shelf

(part #60-604-20)

RSF 123 1U

, 3.5" Deep VersaTools Rack Shelf Kit

(part #60-190-20)

RSB 126 1U

, 6" Deep Basic Rack Shelf (part #60-604-10)

RSU 126 1U

, 6" Deep Universal Rack Shelf Kit

(part #60-190-10)

RSB 129 1U

, 9.5" Deep Basic Rack Shelf (part #60-604-01)

RSU 129 1U

, 9.5" Deep Universal Rack Shelf Kit

(part #60-190-01)

MBB 100

VersaTools Back of the Rack Mounting Kit

(part #70-367-01)

UL rack mounting guidelines

The following Underwriters Laboratories (UL) guidelines

pertain to the safe installation of the equipment in a rack.
1

.

Elevated operating ambient temperature

— If the

equipment is installed in a closed or multi-unit rack

assembly, the operating ambient temperature of the

rack environment may be greater than room ambient

temperature. Therefore, install the equipment in an

environment compatible with the maximum ambient

temperature (Tma = +113 °F, +45 °C) specified by Extron.

2

.

Reduced air flow

— Install the equipment in a rack so that

the amount of air flow required for safe operation of the

equipment is not compromised.

3

.

Mechanical loading

— Mount the equipment in the rack

so that a hazardous condition is not achieved due to

uneven mechanical loading.

4

.

Circuit overloading

— Connect the equipment to

the supply circuit and consider the effect that circuit

overloading might have on overcurrent protection and

supply wiring. Appropriate consideration of equipment

nameplate ratings should be used when addressing this

concern.

5

.

Reliable earthing (grounding)

— Maintain reliable

grounding of rack-mounted equipment. Pay particular

attention to supply connections other than direct

connections to the branch circuit (e.g., use of power strips).
