TP T Series Transmitters • Introduction 1-2
Introduction
PRELIMINAR
Y
About this Manual
This manual describes the procedures for installing and using the Extron TP Series
transmitters, including the TP T 15HD A, TP T 15HD AV, and TP T BNC DA4. The
terms “TP T transmitter” and “transmitter” are used interchangeably throughout
this manual to refer to these three products generically.
About the TP T Series Transmitters
The Extron Twisted Pair (TP) series transmitters provide long-distance distribution
of RGB video, component video, S-video, composite video, and stereo audio
over Extron’s Enhanced Skew-Free ™ A/V UTP cable (recommended) or standard
Category (CAT) 5/5e/6 unshielded twisted pair (UTP), shielded twisted pair (STP),
or foil shielded twisted pair (FTP) cable.
N The TP T Series transmitters are designed for and perform best with Extron
Enhanced Skew-Free cable.
Recommended transmission distances
The minimum reliable transmission distance to all receivers, with the exception of
the TP R 15HD A, is 25 feet (7.6 m). There is no minimum distance for transmission
to the TP R 15HD A.
The maximum distance is determined by the output frequency and resolution. The
following tables specify the recommended maximum transmission distances from
a TP T transmitter to an Extron TP R series receiver, using Extron Skew-Free A/V
UTP cable or UTP CAT 5 cable terminated with CAT 5e or CAT 6 rated connectors.
N Extron recommends using the highest quality cable available and affordable.
Use of pre-terminated and tested cables is also recommended. Cables terminated
on site should be tested before use to ensure that they comply with Category 5e
specifications.
TP T Series transmitter to TP R 15HD A receiver using CAT 5/5e/6 or
Enhanced Skew-Free cable at 60 Hz
Video format
Maximum distance,
high quality
Maximum distance,
variable quality
Component video 700' (213 m) 800' (245 m)
Composite video 700' (213 m) 800' (245 m)
S-video 700' (213 m) 800' (245 m)
640 x 480 500' (150 m) 550' (165 m)
800 x 600 400' (120 m) 450' (135 m)
1024 x 768 300' (90 m) 400' (120 m)
1280 x 960 300' (90 m) 350' (105 m)
1280 x 1024 250' (75 m) 300' (90 m)
1360 x 765 250' (75 m) 300' (90 m)
1365 x 768 250' (75 m) 300' (90 m)
1366 x 768 250' (75 m) 300' (90 m)
1440 x 900 250' (75 m) 300' (90 m)
1400 x 1050 250' (75 m) 300' (90 m)
1600 x 1200 200' (60 m) 250' (75 m)
1920 x 1200 200' (60 m) 250' (75 m)
