PS 124 12 VDC, 4 Amp Power Supply • Installation Manual
3
OUTPUTS
RED-
OVERLOAD
12 VDC TO
TAL OUTPUT
4A
100-240 50-60Hz 1.2A
MAX.
POWER
12V
0.4A MA
X
OUTPUT
S
INPUTS
1
2
3
4
MDA 4V HD-SDI
POWER
12V
.3A MA
X
MDA 5A RC
A
INPUT
OUTPUT
S
1
2
3
5
L
R
4
Extron
PS 124
12VDC 4A
Power Supply
Extron
MDA 4V HD-SDI
HD-SDI Mini Distribution
Amplifer
Extron
MDA 5A RCA
Audio Mini Distribution
Amplifer
Output 6
Output 7
Output 8
Output 1
Output 2
Output 3
Output 4
Output 5
Figure 3 Application Diagram
DC Outputs
d
DC Output connectors — Connect the power cables from
devices that will receive power from the PS 124 to these 3.5 mm
captive screw connectors.
The PS 124 supports up to eight power supply outputs. For
details on limitations and how to wire these captive screw
connectors, see “Output power — wiring the DC output
connectors,” on page 8.
