Extron • RGB 118 & RGB 118 PLUS • User’s Manual
Legend of Icons
The following icons may be used in this manual:
___ Important information – for example, an action or a step that must
be done before proceeding.
___ A Warning – possible damage could occur.
_ A Note, a Hint, or a Tip that may be helpful.
__ Possible Electrostatic Discharge (ESD) damage could result from
touching electronic components.
__ Additional information may be referenced in another section, or in
another document.
