Extron Electronics RGB 118 Plus User Guide User Manual
Page 16
Extron • RGB 118 & RGB 118 PLUS • User’s Manual
Applications
Page 3-3
Large
Screen
Projector
MBC VGA/XGA HR
MBC MAC/QUADRA HR
RGB 118
RGB 118
PLUS
RGB 118 PLUS
Large
Screen
Projector
Hi Res
ECL Buffer
MBC
SUN/APOLLO MONO
Cable
SUN/APOLLO MONO
Workstation
The application diagram below (Figure 2) consists of two
computers with RGB 118 and RGB 118 PLUS interfaces with
access to a projector through a switcher.
Figure 2
The application diagram below (Figure 1) demonstrates an RGB
118 PLUS combined with a Hi Res ECL Buffer and an MBC SUN/
APOLLO MONO cable to interface a high resolution computer/
monitor workstation to a large screen projector.
Figure 1
