Extron • RGB 118 & RGB 118 PLUS • User’s Manual
Computer Compatibility and MBC Cables
Page A-1
Compatible Computers
Amiga 500,1000,2000
Apple IIE/IIC
Apple IIGS
Apple Mac RGB
(Internal Wiring Kit)
Apple Mac SE RGB
(Internal Wiring Kit)
Apple Mac II Series
(Standard Card)
Apple Mac II w/ SuperMac Card
AT&T 6300/6310
AT&T 630
Burroughs 25
DEC 340
IBM 3161,3163,3191,3196 Mono
IBM 3162 Mono
IBM 3164 Color
IBM 3179,3192,3197 Color
IBM 3192D Color
IBM 3270 PC Color
IBM 3270 PCG Color
IBM 3290 Color
IBM 3471/3476 Infowindow
IBM 3472/3477 Terminals
IBM 5291 M-2
IBM PC or Compatible
w/ CGA or EGA card
IBM PC,XT,AT & Compatible w/ MDA Card
IBM PC,XT,AT & Compatible
w/ PGA Card
IBM PS/2 VGA
IBM PS/2 w/ 8514/A Card
IBM VGA/Super VGA/XGA or VGA Plus
Any Laptop w/ VGA output *
(has no external monitor)
NCR PC 6,8 Color
NeXT Monochrome Computers
NeXT Color Computers
Sigma 400 Color
Sun/Apollo Monochrome 9D Workstations
Sun/Apollo Color Workstations
or any Workstation w/RGB out on BNC Connectors.
Sun Sparc Stations
Xerox 6085 and 1186 Computers
MBC Cable Required
MBC Amiga 2000
MBC Apple IIE
MBC Mac II HR
ICWK Mac RGB
ICWK Mac SE RGB
MBC Mac II HR
MBC SuperMac
MBC AT&T 6300
MBC AT&T 630
MBC B-25
ICWK DEC 340
MBC 3161/63/91/96 Mono
MBC IBM 3162
MBC IBM 3164
MBC 3179/92/97
MBC 3192D
MBC IBM 3270 PC
MBC IBM 3270 PCG
MBC IBM 3290
ICWK 3471/3476
MBC IBM INFOWINDOW
MBC 5291 M-2
MBC IBM PCC
MBC IBM PCM
MBC IBM PGA HR
MBC IBM PS/2
MBC IBM VGA HR
MBC IBM VGA HR
LBC VGA HR
MBC NCR PC 6,8
MBC NeXT Cable
MBC Sparc Buffer
MBC Sigma 400
MBC SUN/APOLLO
(also requires ECL Buffer)
MBC RGB BUFFER
MBC Sparc Buffer
MBC XEROX 6085
(also requires Xerox Buffer)
Horz. kHz
15.7
15.7
15.7
22.3
22.0
35.5
35-48
26.0
54
19.8
31.5
27.6
25.9
27.6
23.0
23.0
23.5
24.0
29.6
31.0
38.0
18.3
15.7/21.8
18.4
31.5
31.5/35.5
35.1
31.5-<50.0
31.5
23.6
62.0
63.0
31.4
63.8
64.0-<125.0
64-89
28.0/37.0
Vert. Hz
60
60
60
60
60
67
67
60
60
60
60
65
65
65
60
60
63
63
73
60
68
50
60
50
70
60/70
87/43
60/80
60/70
55
68
68
60
66
60
60/70
76
*When using most laptops to display on large-screen projectors, the computer’s internal LCD display is
deactivated.
