1-3
PVT Series (Rack Mount Models) • Introduction
About the PVT CV
The P�T C� Twisted Pair Transmitter is a 1/8 rack mounting
model that can transmit composite video and stereo audio to the
PVS 204SA switcher. This model can also be mounted under a
desk or shelf, or on certain projector poles.
AUDIO
IN
VIDEO
IN
VIDEO OUT
L
R
PVT CV
Figure 1-1 — PVT CV face and rear panel
About the PVT RGB
The P�T RGB Twisted Pair Transmitter is a 1/4 rack mounting
model that can transmit high resolution (RGB) video and an
associated stereo audio signal to the PVS 204SA switcher. It has
a local monitor output for image monitoring. This model can
also be mounted under a desk or shelf, or on certain projector
poles.
PVT RGB
INPUT
MONITOR OUT
RGB A OUT
RGB B OUT
PVT RGB
Figure 1-2 — PVT RGB face and rear panel
