About the PVT Transmitters
The Extron P�T Series (Pole�ault P�T Series (Pole�ault ™ Twisted Pair Transmitters)
are a series of cost effective twisted pair transmitters that work
exclusively with the PVS 204SA, a four-input twisted pair
switcher with a built in power amplifier.
PVT transmitters can transmit composite video and stereo audio
or high resolution video (RGB) and stereo audio to the
PVS 204SA switcher over CAT 5 twisted pair cable, up to a
distance of 100 feet. All transmitters are remotely powered
via the twisted pair cable when connected to the PVS 204SA
switcher.
N
This manual covers the rack mount models only.
For Decora
® and AAP models, refer to the manual (part
number 68-1259-01) for those devices.
N
PVT series of transmitters are compatible ONLY
with the PVS 204SA switcher.
N
For PVS 204SA installation and operation information,
refer to the manual supplied with the device.
The PVT transmitter rack mount models can be mounted on 1U
19" or standard rack shelves, or mounted under or on desks.
The PVT series rack mount models are as follows:
PVT CV — Transmits composite video and stereo audio.
PVT RGB, PVT SW RGB — Transmits computer (RGB) video
and stereo audio.
PVT RGB CV — Transmits composite video, computer video
and two stereo audio signals.
See the "About the PVT xx" sections in this chapter for details.
The PVT transmitters are part of a system for distribution of
composite or computer video and audio, over Extron Enhanced
Skew-Free™ A/V UTP Cable, or any CAT 5, 5e, or 6 shielded
twisted pair (STP), unshielded twisted pair (UTP), or foil
shielded twisted pair (FTP) cable.
Transmission distance
The maximum distance is determined by the frequency and
resolution of the signal that is input to the transmitter. However,
all PVT models can transmit signals to the PVS 204SA switcher
if it is located not more than 100 feet away. The optimum
distance is between 50 and 75 feet.
