A-2
Reference Material
PVT Series (Rack Mount Models) • Reference Material
Specifications
N These transmitters are compatible only with the Extron
PVS 204SA. They are not compatible with other models of
twisted pair receivers.
Video — RGB (RGB models)
Gain ................................................ Unity
Video input and loop-through — RGB (RGB models)
Number/signal type ..................... 1 VGA-UXGA RGBHV, RGBS
(2 for PVT SW RGB, and 1 buffered loop
through)
Connectors ..................................... 1 female 15-pin HD (2 for PVT SW RGB)
Nominal level ................................ 0.7 Vp-p for RGB
Minimum/maximum levels ........ Analog: 0.3 V to 1.5 Vp-p with no offset
Impedance ..................................... 75 ohms
Horizontal frequency .................... 15 kHz to 130 kHz
Vertical frequency .......................... 30 Hz to 150 Hz
Return loss ..................................... <-30 dB @ 5 MHz
DC offset (max. allowable)........... 250 mV
Video output — RGB (RGB models)
Number/signal type ..................... 2 analog proprietary signals
Connectors .................................... 2 female RJ-45
Sync — RGB (RGB models)
Input type ...................................... RGBHV, RGBS
Input level ..................................... 3.5 V to 5.5 Vp-p, unterminated
Input impedance .......................... 510 ohms
Max. input voltage ........................ 5.5 Vp-p
Video — composite video (CV models)
Gain ................................................ Unity
Differential phase error ............... <1.0º at 3.58 MHz and 4.43 MHz
Differential gain error .................. <1.0% at 3.58 MHz and 4.43 MHz
Video input — composite video (CV models)
Number/signal type ..................... 1 composite video
Connectors .................................... 1 female RCA
Nominal level ................................ 1 Vp-p for composite video
Minimum/maximum levels ........ Analog: 0.3 V to 1.5 Vp-p with no offset
