Introduction
This section provides general descriptions of the this guide and the PowerCage FOX AEX
104. Topics in this section include:
• About This Guide
• About the PowerCage FOX AEX 104
• Features
• Application Diagrams
About This Guide
This guide provides installation, configuration, and operation information about the two
models of the PowerCage FOX AEX 104 fiber optic audio extractors. The PowerCage
FOX AEX 104 is available in two transmission modes:
• PowerCage FOX AEX 104 SM — 4-input singlemode audio extractor, containing
1310 nm SFP modules.
• PowerCage FOX AEX 104 MM — 4-input multimode audio extractor, containing
850 nm SFP modules.
In this guide, the term “PowerCage FOX AEX 104” refers to either
PowerCage FOX AEX 104 singlemode or PowerCage FOX AEX 104 multimode models.
NOTE: A color-coded sticker on the rear panel identifies the type: orange for
multimode and yellow for singlemode.
About the PowerCage FOX AEX 104
The PowerCage FOX AEX 104 is a four input fiber audio extraction product that extracts
local audio in a fiber matrix application. It is a board to be installed in an Extron PowerCage
enclosure.
NOTES: • The multimode and singlemode PowerCage FOX AEX 104 audio extractors are
physically and functionally identical with the exception of the effective range
of transmission.
• The FOX audio extractor is compatible with all FOX products with the
exception of the FOX 3G HD-SDI transmitter and receiver products.
• The PowerCage FOX AEX 104 MM and the PowerCage FOX AEX 104 SM are
not compatible with each other.
1 PowerCage FOX AEX 104 • Introduction
