Frequency response ........................ 20 Hz to 20 kHz, ±0.5 dB
THD + Noise ................................... 0.10% @ 1 kHz at nominal level
S/N ................................................. >80 dB at maximum output (unweighted)
Audio bits per sample ..................... 18 bits per channel, 2 channels (L, R)
Sampling rate ................................. 48 kHz
Audio input — See the transmitter specifications
Audio output
Number/signal type ........................ 4 balanced/unbalanced stereo or 8 balanced/unbalanced mono
Connectors .................................... (4) 3.5 mm captive screw connectors, 5 pole
Impedance ..................................... 50 ohms unbalanced, 100 ohms balanced
Nominal level ................................. +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level ............................... >+11 dBu, balanced at 1% THD+N
Audio Delay ................................... 1.5 frames
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
General
Power ............................................ Supplied by a PowerCage 1600 System Enclosure
Power consumption
System ..................................... Enclosure without boards: 12.4 watts
PowerCage FOX AEX board ..... 19.7 watts
Power input requirement
for boards ...................................... 12 VDC, 1.0 A, supplied by the PowerCage enclosure
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Enclosure: fans, front to back
Boards: convection, within the PowerCage enclosure
Thermal dissipation ........................ 67.2 BTU/hr
Mounting
Rack mount ............................. Yes, with optional rack shelf
Furniture mount ...................... Yes, with optional under desk mounting kit
Enclosure type ................................ Metal
Enclosure dimensions
PowerCage enclosure .............. 5.25” H x 17.0” W x 12.25” D (3U high, full rack wide)
13.3 cm H x 43.2 cm W x 31.2 cm D
(Depth excludes connectors on the optional boards. Width excludes rack ears.)
PowerCage FOX AEX board ..... Fits a double slot opening in a PowerCage enclosure
Product weight
PowerCage enclosure .............. 11.6 lbs (0.5 kg)
PowerCage FOX AEX board ..... 0.8 lbs (0.4 kg)
Shipping weight
PowerCage enclosure .............. 13 lbs (6 kg)
PowerCage FOX AEX board ..... 2 lbs (1 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, FDA Class 1, UL
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTES: • All nominal levels are at ±10%.
• Specifications are subject to change without notice.
8.0-033012-D1
PowerCage FOX AEX 104 • Reference Information 10
