Changing the Input Data Rate
The DIP switch on the main board switches the PowerCage FOX AEX 104 between 2G and
4G input data rates.
1.
If necessary, remove the PowerCage FOX AEX 104 board from the PowerCage
enclosure.
2.
Use an Extron Tweeker to move DIP switch 2 up (On position) for 2G input data
rates or down (Off position) for 4G input data rates.
3.
Reinstall the PowerCage FOX AEX 104 board into the PowerCage enclosure to cycle
power back to the board (see
Installing a Board in the Enclosure
on page 12).
DIP switch 1 is a spare. The default rate is 4G (Off or down).
NOTE: Selectable rates apply to all extraction points. They are not for individual inputs.
CAUTION: Ensure all fiber extenders within the system are compatible with the selected
input data rate.
O
N
1 2
PowerCage FOX AEX 104 • Installation and Operation
8
