Mlm 226 faceplates installation guide, cont’d, Mlm 226 7gwp template – Extron Electronics MLM 226 Faceplates User Manual
Page 8
MLM 226 Faceplates Installation Guide, cont’d
MLM 226 Faceplates • Installation Guide
8
© 2007 Extron Electronics. All rights reserved.
Extron Electronics, USA
1230 South Lewis Street
Anaheim, CA 92805
800.633.9876 714.491.1500
FAX 714.491.1517
Extron Electronics, Europe
Beeldschermweg 6C
3821 AH Amersfoort, The Netherlands
+800.3987.6673 +31.33.453.4040
FAX +31.33.453.4050
Extron Electronics, Asia
135 Joo Seng Rd. #04-01
PM Industrial Bldg., Singapore 368363
+800.7339.8766 +65.6383.4400
FAX +65.6383.4664
Extron Electronics, Japan
Kyodo Building, 16 Ichibancho
Chiyoda-ku, Tokyo 102-0082
Japan
+81.3.3511.7655 FAX +81.3.3511.7656
www.extron.com
MLM 226 7GWP template
2.9"
(7.4 cm)
12.7"
(32.3 cm)
SURFACE CUT-OUT
AREA FOR
FURNITURE MOUNT
13.665"
(34.71 cm)
Cut-Out Template for Extron's MLM 226 7GWP
TEMPLATE IS NOT FULL SIZE.
To install MLC 226 IP
and MLM 226 7GWP
directly into furniture,
cut along this line.
Top Panel
Location of MLC 226 IP
4.5"
(11.4 cm)
