MLM 226 Faceplates • Installation Guide
MLM 226 5GWP and MLC 226 IP AAP template
2.9"
(7.4 cm)
8.9"
(22.6 cm)
SURFACE CUT-OUT
AREA FOR
FURNITURE MOUNT
10.04"
(25.5 cm)
Cut-Out Template for Extron's MLM 226 5GWP and MLC 226 IP AAP
TEMPLATE IS NOT FULL SIZE.
To install MLC 226 IP
and MLM 226 5GWP
directly into furniture,
cut along this line.
Top Panel
Location of MLC 226 IP
4.5"
(11.4 cm)
