MLM 226 Faceplates Installation Guide, cont’d
MLM 226 Faceplates • Installation Guide
6
MLM 226 3GWP and MLC 226 IP template
6.4"
(16.26 cm)
Cut-Out Template for Extron's MLM 226 3GWP and MLC 226 IP
TEMPLATE IS NOT FULL SIZE.
To install MLC 226 IP
and MLM 226 3GWP
directly into furniture,
cut along this line.
Top Panel
2.9"
(7.4 cm)
5.4"
(13.7 cm)
SURFACE CUT-OUT AREA
FOR FURNITURE MOUNT
4.5"
(11.4 cm)
Location of MLC 226 IP
