Control/remote — external device (pass-through) from the HDMI input
Serial control port input/output ...... RS-232 via (1) 3.5 mm, 3 pole captive screw connector
Baud rates ...................................... Up to 38400 bps at up to 600' (183 m) (Higher data rates and distances are possible.
Performance varies based on baud rate and cable length.)
NOTE: Protocol is mirrored between the transmitter and the receiver.
Serial control pin configuration ....... Captive screw connector: 1 = Tx, 2 = Rx, 3 = GND
Control/remote — external device (pass-through, unidirectional or
bidirectional) from the MTP input
Serial control port input/output ...... RS-232 via (1) 3.5 mm, 5 pole captive screw connector (3 poles are used)
Baud rates ...................................... Up to 38400 bps at up to 600' (183 m) (Higher data rates and distances are possible.
Performance varies based on baud rate and cable length.)
NOTE: Protocol is mirrored between the transmitter and the receiver.
Serial control pin configuration ....... Captive screw connector: 1 = Tx, 2 = Rx, 3 = GND
General
Recommended cable type .............. Shielded or unshielded
MTP input ................................ CAT 5/5e/6
HDMI digital input ................... CAT 5/5e/6, Extron DTP26
External power supply .................... 100 VAC to 240 VAC, 50-60 Hz, external; to 12 VDC, 1 A, regulated
Power input requirements .............. 12 VDC, 0.8 A
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, no vents
Thermal dissipation
115 VAC, 60 Hz ....................... 16.7 BTU/hr
240 VAC, 50 Hz ....................... 18.1 BTU/hr
Mounting
Rack mount ............................. Yes, with optional 1U rack shelf
Furniture mount ...................... Yes, with optional under-desk mounting kit
Pole mount .............................. Yes, with optional projector mounting kit
Enclosure type ................................ Metal
Enclosure dimensions ..................... 1.7" H x 8.75" W x 3.0" D (half rack wide)
(4.3 cm H x 22.2 cm W x 7.6 cm D)
(Depth excludes connectors.)
Product weight ............................... 0.8 lbs (0.4 kg)
Shipping weight ............................. 2 lbs (1 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, UL
UL rated for use in plenum airspaces: meets UL 2043 for heat and smoke release,
excluding the power supply.
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTE: All nominal levels are at ±10%.
NOTE: Specifications are subject to change without notice.
MTP/HDMI U R • Reference Information 15
