Video input
Number/signal type
MTP input ................................ 1 set of proprietary analog signals
HDMI digital input ................... 1 set of proprietary digital signals
Connectors
MTP input ................................ 1 female RJ-45
HDMI digital input ................... 2 female RJ-45
Video output
Number/signal type
Analog output ......................... 1 RGBHV, RGBS, component video (bi-level and tri-level), S-video, composite video
(follows input type)
HDMI digital output ................. 1 single link HDMI (or DVI-D*)
Connectors
Analog output ......................... 1 female 15-pin HD for RGB
3 female BNC for Y, R-Y, B-Y
1 female 4-pin mini DIN for S-video (Y/C)
1 female BNC for composite video
HDMI digital output ................. 1 female HDMI type A
Nominal levels ................................ Analog outputs:
1 Vp-p for Y of component video and S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
Minimum/maximum levels .............. Analog outputs: 0.8 V to 1.2 Vp-p
Impedance ..................................... Analog outputs: 75 ohms (during video output only)
Return loss ..................................... Analog outputs: <-30 dB @ 5 MHz (during video output only)
DC offset ....................................... Analog outputs: <±20 mV with input at 0 offset
Sync — analog outputs
Output type ................................... RGBHV, RGBS, component video (bi- or tri-level)
Standards ....................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Output level ................................... 4.0 V to 5.0 Vp-p, unterminated
Output impedance ......................... 87 ohms (24 mA)
Polarity ........................................... Positive or negative (selectable)
Audio — from MTP input
Gain ............................................... Unbalanced output: 0 dB; balanced output: +6 dB
Frequency response ........................ 20 Hz to 20 kHz, ±1 dB
THD + Noise ................................... 0.15% @ 1 kHz, 0.3% @ 20 kHz at nominal level
S/N ................................................. >70 dB at maximum output (unweighted)
Audio input — from MTP input, see MTP transmitter's audio output specifications
Number/signal type ........................ 1 set of proprietary analog signals
Connectors .................................... 1 female RJ-45
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
Audio output — from MTP input
Number/signal type ........................ 2 mono, balanced/unbalanced
Connectors .................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance ..................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ...................................... ±1 dB channel to channel
MTP/HDMI U R • Reference Information 14
