Reference
Information
This section provides information about:
• Specifications
• Part Numbers and Accessories
Specifications
Video
MTP input
Gain ........................................ Unity
Maximum resolution
Analog ............................... Up to 2048x1080 or 1080p @ 60 Hz
Signal transmission distance, analog
Resolutions
MTP/HDMI U R
Analog Signal Maximum Transmission Distances
1024x768 @ 60 Hz
1920x1200, 2048x1080
1080p @ 60 Hz Up to 600' (183 m)
Up to 400' (122 m)
HDMI digital input
Maximum data rate ................. 4.95 Gbps (1.65 Gbps per color)
Maximum pixel clock ............... 165 MHz
Maximum resolution
Digital ................................ Up to 1920x1200 or 1080p @ 60 Hz
Signal transmission distance, digital
CAT 5/5e/6 Cable Extron DTP26
UTP STP Cable
200' (60 m) 200' (60 m) 200' (60 m)
100' (30 m) 125' (38 m) 150' (46 m)
Resolutions
MTP/HDMI U R
Digital Signal Maximum Transmission Distances
1024x768,
720p, 1080i @ 60 Hz
1600x1200, 1920x1200,
1080p @ 60 Hz
8-bit Color Depth
NOTE: The transmission distance varies greatly depending on the signal resolution and on the type of cable,
graphics card, and display used in the system.
Formats ................................... RGB and YCbCr digital video
Standards ................................ DVI 1.0, HDMI 1.2
MTP/HDMI U R • Reference Information 13
