Digital signal output — The MTP/HDMI U R outputs a digital HDMI signal
through this female HDMI connector. See the "
HDMI Connector Pin
Assignments" section,
for pin wiring details.
d
RS-232 Control Pass-thru connector — Connect a serial communications port to this
3.5 mm, 3-pole captive screw connector for bidirectional RS-232 communication (digital
side). See the "
Control Connector Wiring"
section, to wire the connector.
NOTE: The RS-232 connector can also transmit one-way modulated infrared (IR)
signals.
e
Analog signal input — Connect an MTP transmitter (or a DA or a switcher) using
twisted pair cable to this RJ-45 connector.
CAUTION: Do not connect the twisted pair input cables to a LAN port, or connect
a LAN cable to the digital or MTP input ports.
NOTE: The transmission distance varies greatly depending on the signal resolution
and on the type of cable, graphic card, and display used in the system.
Maximum Transmitter to Receiver Distance (Analog Signals)
Video Format
With Pre-Peak Off
Feet (Meters)
With Pre-Peak On
Feet (Meters)
Max. Distance
(High Quality)
Feet (Meters)
Max. Distance
(Variable Quality)
Feet (Meters)
Composite,.
S-video,.
Component.Video
800.(245)
1000.(300)
640.x.480
<300.(90)
>350.(105)
700.(215)
750.(240)
800.x.600
<300.(90)
>350.(105)
550.(165)
650.(200)
1024.x.768*
<300.(90)
>350.(105)
500.(150)
600.(185)
1280.x.960
<300.(90)
>350.(105)
400.(120)
500.(150)
1280.x.1024*
<250.(75).
>300.(90).
350.(105)
450.(135)
1360.x.765
<250.(75).
>300.(90).
400.(120)
500.(150)
1365.x.768
<250.(75).
>300.(90).
400.(120)
450.(135)
1366.x.768
<250.(75).
>300.(90).
400.(120)
450.(135)
1400.x.1050
<250.(75).
>300.(90).
350.(105)
400.(120)
1440.x.900
<250.(75).
>300.(90).
350.(105)
400.(120)
1600.x.1200*
<250.(75).
>300.(90).
300.(90).
450.(135)
1920.x.1200
<250.(75).
>300.(90).
300.(90).
400.(120)
2048.x.1080
<250.(75).
>300.(90).
300.(90).
400.(120)
HDTV.720p
<250.(75).
>300.(90).
400.(120).
500.(150)
HDTV.1080i
<250.(75).
>300.(90).
300.(90).
400.(120)
.HDTV.1080p
<250.(75)
>300.(90)
300.(90)
400.(120)
*.same spec at 75 Hz
Figure 5.
Maximum Transmission Distances for Analog Signals at 60 Hz
