MSG Matrix Switchers • Specifications A-4
Specifications — MSG0804 and MSG0808
MSG0808-4,
MSG0808HR-4 .................. 8 stereo, balanced/unbalanced, line level
Connectors
MSG0804-4,
MSG0804HR-4 .................. (4) 3.8 mm captive screw connectors, 5 pole
MSG0808-4,
MSG0808HR-4 .................. (8) 3.8 mm captive screw connectors, 5 pole
Impedance .................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ...................................... ±0.4dB channel to channel
Maximum level (Hi-Z) ................ >+12dBu, balanced or unbalanced at stated %THD+N
Maximum level (600 ohm) ......... >+20dBm, balanced or unbalanced at stated %THD+N
0dBu = 0.775 volts (RMS).
Control/remote — switcher
Serial control ports ...................... RS-232, RS-422, RS-485 on a 3.8 mm captive screw connector
Baud rate and protocol ............... 1200/2400/4800/ 9600/19200/38400 (default 8-bit, 1 stop bit, no parity, no
flow control, 9600 baud)
Serial control pin configurations RS-232 — 2 = TX, 3 = RX, 5 = Gnd
RS-422/RS-485 — 2 = TX+, 6 = TX-, 3 = RX+, 7 = RX-, 1 and 5 = Gnd
Program control ........................... ICS100 Control Software
General
Power ............................................. 100VAC to 240VAC, 50/60 Hz, 25 watts, internal, autoswitchable
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing
Rack mount ................................... Yes, with included IN9084B rack mount kit
Enclosure type .............................. Metal
Enclosure dimensions ................. 5.2" H x 17" W x 11.4" D (3U high, full rack width)
13.3 cm H x 43.3 cm W x 28.8 cm D
(Depth excludes connectors and knobs. Width excludes rack ears.)
Product weight ............................. 12.25 lbs (5.6 kg)
Shipping weight .......................... 15 lbs (6.8 kg)
DIM weight .............. 26 lbs
Vibration ....................................... ISTA/NSTA 1A in carton (International Safe Transit Association)
Listings .......................................... ETL (UL1950)
Compliances ................................. CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
