MSG Matrix Switchers • Remote Control
5-7
Set channel volume level - right
[VOLRooxxx]
Sets the right channel volume level for a specific output.
• Where:
oo
= 01 - 04 (MSG0804) or 01 - 08 (MSG0808) for output.
xxx
= -550 - 090
Note
: 090 equals maximum gain (+9dB), 000 equals factory
default (unity gain), and -550 equals minimum gain (-55dB).
Change output volume level - global
[VOLx]
Changes the volume level for all outputs.
• Where:
x
= + (plus sign) to increment the output volume.
x
= - (minus sign) to decrement the output volume.
x
= @ to return the output volume to factory default.
x
= ? to request the current volume level.Front Panel
Executive.
Change channel volume level - global
[VOLoox]
Changes the channel volume level for a all output.
• Where:
oo
= 01 - 04 (MSG0804) or 01 - 08 (MSG0808) for output.
x
= + (plus sign) to increment the output volume.
x
= - (minus sign) to decrement the output volume.
x
= @ to return the output volume to factory default.
x
= ? to request the current volume level.
Ramp volume level - specific
[VOLRMPoox]
Starts the volume ramp function for a specific output.
• Where:
oo
= 01 - 04 (MSG0804) or 01 - 08 (MSG0808) for output.
x
= + (plus sign) to ramp up.
x
= - (minus sign) to ramp down.
Stop volume ramp
[VOLSTOP]
Stops the volume ramp function.
Change input volume level - specific
[VINiix]
Changes the volume level for a specific input.
• Where:
ii
= input 01 - 08.
x
= + (plus sign) to increment the output volume.
x
= - (minus sign) to decrement the output volume.
x
= @ to return the output volume to factory default.
x
= ? to request the current volume level.
Set Input volume level - specific
[VINiixxx]
Sets the volume level for a specific input.
• Where:
ii
= input 01 - 08.
xxx
= -640 - 000
Note
: 000 equals maximum (factory default), -640 equals
minimum gain.
